The Synergy of Injection-Molded Plastics, CNC-Machined Parts, and Rapid Injection Molding

Bost delivers expert solutions combining Injection-Molded Plastics, Rapid Injection Molding, and CNC-Machined Parts to accelerate product development. Discover how our precision manufacturing enhances efficiency and quality for your projects. Trust Bost for seamless, innovative production services.

​In modern manufacturing, plastic parts have become core components in home appliances, automobiles, medical care, electronics, and other fields due to their advantages of light weight, corrosion resistance, and good formability. The guarantee of their production efficiency and precision relies on the in-depth synergy of three core technologies: injection-molded plastics, CNC-machined parts, and rapid injection molding. These three technologies do not exist in isolation but form a complete chain of "basic molding - precision optimization - efficiency improvement", jointly meeting the core needs of "high precision, fast delivery, and low cost" for plastic parts in different scenarios.

​

First, injection-molded plastics is the "cornerstone technology" for mass production of plastic parts. Its core principle is to feed granular plastic raw materials (such as PP, ABS, PC, PA, etc.) into the barrel of an injection molding machine. The heating coils in the barrel melt the raw materials into a flowable state, and then the screw injects the molten plastic into the pre-customized metal mold cavity at high pressure and high speed. After the plastic cools and solidifies in the mold, the mold opening and closing mechanism drives the mold to separate, and the ejection device pushes out the molded part, completing a single injection cycle. The characteristics of different raw materials determine their application scenarios: PP (polypropylene) is often used in food containers and automobile bumpers due to its strong chemical resistance and good toughness; ABS (acrylonitrile-butadiene-styrene copolymer) combines rigidity and impact strength, making it the first choice for home appliance shells and computer keyboards; PC (polycarbonate) has high light transmittance and high temperature resistance, and is widely used in optical lenses and medical equipment shells. However, affected by mold processing precision, raw material shrinkage, and injection pressure fluctuations, parts just after injection molding may have dimensional deviations of 0.1-0.5 mm, or tiny shrinkage marks and flash on the surface, which requires CNC-machined parts technology for "precision repair".​

CNC-machined parts technology is the "gatekeeper" of plastic part precision. Relying on the computer numerical control (CNC) system, it converts the design drawings of parts into digital programs, controls the tool movement trajectory of milling machines, lathes, drilling machines, and other equipment, and performs secondary processing on injection-molded plastic parts. For example, for parts that need to be assembled with threaded holes, CNC drilling machines can accurately process standard internal threads through high-speed rotating taps; for optical parts with extremely high surface flatness requirements, CNC milling machines use diamond tools for fine cutting, controlling the surface roughness below Ra0.02 microns. More importantly, CNC machining can adjust process parameters according to the physical properties of plastics: when processing brittle PC parts, the cutting speed is reduced and cooling spray is increased to avoid part cracking; when processing tough PA (polyamide) parts, the feed rate is increased to reduce tool wear. Through this "customized processing", the dimensional accuracy of parts can be stably controlled at the 0.01 mm level, fully meeting the assembly tolerance requirements of high-end equipment.

​

When the market faces rapid product iteration (such as consumer electronics new product development) or small-batch emergency orders (such as emergency accessories for medical equipment), rapid injection molding technology becomes an "efficiency accelerator". It is not a subversion of traditional injection molding, but achieves cycle shortening through three major technical optimizations: first, adopting modular mold design, dividing the mold into a basic mold base and replaceable cavity modules. Replacing different cavity modules only takes 20-30 minutes, while traditional integral mold replacement takes 2-3 hours; second, applying a hot runner system, which eliminates the cooling and removal of "gate sprue" in traditional injection molding, not only reducing raw material waste by 30% but also shortening the single cycle time by 15%-20%; third, equipping an intelligent temperature control system, which real-time monitors the mold temperature through infrared sensors and automatically adjusts the heating power to avoid part defects caused by temperature fluctuations and reduce the rework rate. Taking an automotive electronics company as an example, its new car-mounted sensor shell required small-batch trial production verification. Through rapid injection molding technology, it only took 7 days from mold design to the delivery of the first 100 parts, while traditional injection molding required at least 20 days, greatly accelerating the product development progress.

​

Whether it is plastic buckles for automotive interiors (requiring mass injection + CNC drilling), plastic components for medical equipment (requiring high-precision processing + rapid delivery), or plastic shells for electronic equipment (requiring specific raw material injection + surface finishing), BOST can build a production foundation through injection-molded plastics technology, optimize precision with CNC-machined parts technology, and improve efficiency relying on rapid injection molding technology, forming a "one-stop" solution. By deeply integrating the three technologies, BOST, as a professional injection-molded plastics company, has solved the efficiency and precision problems of plastic part production for thousands of enterprises. For example, a medical equipment manufacturer once failed in equipment assembly due to the substandard precision of traditional injection-molded parts. BOST adjusted the injection parameters (such as reducing the injection speed and extending the holding time) and corrected the key dimensions with CNC milling, finally increasing the part qualification rate from 60% to 99.5%. In addition, BOST has also established a raw material database, presetting optimal injection and processing parameters for more than 20 kinds of commonly used plastics such as PP, ABS, and PC. This not only shortens the production debugging time but also recommends the most suitable raw materials according to the customer's requirements for part performance (such as temperature resistance and impact resistance), further confirming that BOST is a professional injection-molded plastics company.​
